Vacuum Brazed Tuck Point Blade Crack Chaser Blade
product introduction
The Tuck Point Blade from Xingong is a versatile and efficient tool designed for fast removal of mortar joints in brick, block, or stone surfaces. These blades are also ideal for grooving and milling on stone surfaces, making them suitable for a wide range of applications on both exterior and interior building surfaces. Available in various designs and sizes, these blades offer precision and high performance in masonry and stonework.
product advantage
• Efficient Removal: The Vacuum Brazed Tuck Point Blade and Crack Chaser Blade offer extra fast and efficient removal of mortar joints in brick, block, or stone, suitable for both exterior building surfaces and interior floors and walls.
• Multi-Functional: Serves as grooving wheels for stone and soft building materials, ideal for fast grooving or milling on marble and limestone surfaces.
• Design Variants: Available in Segmented Tuck Point Blade design, V-Shaped, or U-Shaped Crack Chaser Blades to cater to different cutting and grooving needs.
• Various Sizes: Blades are available in sizes ranging from 4" to 14" to accommodate different project requirements.
• Safety: Advanced manufacturing processes reduce potential hazards during use.
• Cost-Effective: Combines performance and price, offering excellent value for money.
technical data
| Diameter(Inch/mm) | Segment Height(mm) | Grit Size(#) | Connection | Product Name |
| 4"/100 | 3.0-10.0 | 30#-80# | 7/8“-5/8"/M14/5/8"-11 | Tuck Point Blade |
| 4.5"/115 | 3.0-10.0 | 30#-80# | 7/8“-5/8"/M14/5/8"-11 | Tuck Point Blade |
| 5"/125 | 3.0-10.0 | 30#-80# | 7/8“-5/8"/M14/5/8"-11 | Tuck Point Blade |
| 6"/150 | 3.0-10.0 | 30#-80# | 7/8“-5/8"/M14/5/8"-11 | Tuck Point Blade |
| 7"/180 | 3.0-10.0 | 30#-80# | 7/8“-5/8"/M14/5/8"-11 | Crack Chaser Blade |
| 10"/250 | 3.0-10.0 | 30#-80# | 7/8“-5/8"/M14/5/8"-11 | Crack Chaser Blade |
| 12"/300 | 3.0-10.0 | 30#-80# | 7/8“-5/8"/M14/5/8"-11 | Crack Chaser Blade |
| 14"/350 | 3.0-10.0 | 30#-80# | 7/8“-5/8"/M14/5/8"-11 | Crack Chaser Blade |
PACKAGING & SHIPPING
• For urgent orders with lighter weight or samples, we recommend using express delivery.
• For regular orders weighing over 45kgs, air cargo is recommended.
• For large diameter saw blades or heavy items, shipping by sea is recommended.
Xingong will provide recommendations based on the specific requirements of each order.
