Precision 4-Axis Bridge Saw for Granite and Marble
product video
product introduction
The Xingong 4 Axis Bridge Saw is ideal for cutting slabs, tiles, marble, artificial stone, granite, cement products, and other building materials with special-shaped edges or multi-functional capabilities. It is highly suitable for deep processing in home decoration or municipal engineering, making it the preferred equipment for specialized factories.
product advantage
• Versatility: Cuts various materials like marble, granite, and artificial stone.
• Multi-functionality: Suitable for both slabs and tiles, enhancing its utility.
• Ideal for Specialized Use: Perfect for home decoration and municipal engineering projects.
• Precision: Ensures accurate cutting for high-quality results.
• Efficiency: Designed for deep processing, optimizing production processes.
technical data
| Model | XGM-4AL | Unit |
| Blade diameter | 350-400 | mm |
| Worktable size | 3200×2000 | mm |
| Max. cutting size | 3200×2000×70 | mm |
| Max. chamfering size | 3200×1800×70 | mm |
| Saw blade horizontal rotation degrees | 0-360° | ° |
| Chamfering orientation | 0-90-180-270° | ° |
| Saw blade chamfering degrees | 0-45° | ° |
| Worktable tilting degrees | 0-85° | ° |
| Main motor power | 15 | kw |
| Total power | 22.5 | kw |
| Water Consumption | 3.5 | m³/h |
| Gross weight | 3700 | kg |
| Overall dimensions | 5000×3000×2750 | mm |
