Heavy Duty 3 Axis Bridge Saw for Granite and Marble
PRODUCT VIDEO
product introduction
Xingong 3 Axis Bridge Saw (Heavy Duty) features PLC control through a user-friendly touch interface and includes wireless remote control for flexible man-machine interaction. It utilizes high-quality components from renowned international brands. The machine employs a robust structure with a cross frame oil-diffused double V track and durability, offering a perfect combination for users. The integration of the fuselage and workbench base in a one-piece self-supporting steel structure not only simplifies installation and transportation but also guarantees the machine's stability during operation. This setup ensures reliable performance and precise cutting capabilities, making it an ideal choice for heavy-duty applications. The machine's design emphasizes flexibility through its wireless remote control and intuitive touch-operating interface.
product advantage
• Advanced Control and Interface: PLC control with a user-friendly touch interface for easy operation.
• High-Quality Components: Utilizes components from renowned international brands, ensuring reliability.
• Robust Structure: Features a durable cross frame oil-diffused double V track for stability and precision.
• Easy Installation and Transportation: One-piece self-supporting steel structure simplifies setup and guarantees stability during operation.
• Heavy-Duty Performance: Ideal for demanding applications with reliable performance and precise cutting capabilities.
• Flexibility: Emphasizes flexibility with wireless remote control and an intuitive touch-operating interface.

technical data
Model | XGM-3ALH-1 | XGM-3ALH-2 | unit |
Blade diameter | Φ350-Φ600 | Φ350-Φ600 | mm |
Max. processing size(L×W×H) | 3200×2000×180 | 3200×2000×180 | mm |
Dimensions of Worktable (L×W) | 3200×2000 | 3200×2000 | mm |
Head rotating degree | 0°-90° | 0°-90° | n° |
Blade tilting degree | 0°-45° | 0°-45° | n° |
Worktable flipping degree | 0°-85° | 0°-85° | n° |
Table rotating degree | --- | 0°-45°-360° | n° |
Main motor power | 18.5 | 18.5 | kw |
Water consumption | 3.5 | 3.5 | m³/h |
Overall dimension (L×W×H) | 6000×3500×2660 | 6000×3500×2800 | mm |
Weight | 4800 | 5000 | kg |
